Light-ring Shape LED Showing The Hardcore Style

Nearly 200 LED light sources on the exterior "Disconnected" light strip design inspiration

Stylish Interior, Technological Configuration, Enhance Driving Pleasure

12.3-inch full-size LCD dashboard, 10 inch center control display

Deeply Hidden Details To Show The Mechanical Aesthetics

Exposed hinge structure, three-section opening body with independent opening trunk window, flexible body, versatile shape

Excellent Passing Ability

  • Approch angle 37°
  • Departure angle 31°
  • Ramp angle 23°
  • Maximum fording depth >600mm
  • Maximum trench-crossing width 500mm
  • Roadblock-crossing height 350mm


Pricing & Specs
B40 PLUS
Diesel
R574,500
B40 PLUS
Petrol
R609,500
B40 PLUS
City Hunter Diesel
R604,500
B40 PLUS
City Hunter Petrol
R639,500
B40 PLUS
City Hunter P-8AT
R674,500
B40 PLUS
Champion
R659,500
B40 PLUS
Champion 8AT
R699,500
Displacement (cm3)
1999
1981
1999
1981
1981
1981
1981
Cylinder configuration
In-line 4 cylinder turbo
In-line 4 cylinder turbo
In-line 4 cylinder turbo
In-line 4 cylinder turbo
In-line 4 cylinder turbo
In-line 4 cylinder turbo
In-line 4 cylinder turbo
Maximum power (kW @ r/min)
110 @ 4000 r/min
160 @ 5500 r/min
110 @ 4000 r/min
160 @ 5500 r/min
165 @ 5500 r/min
160 @ 5500 r/min
165 @ 5500 r/min
Maximum torque (Nm @ r/min)
350 @ 1800-2800 r/min
320 @ 1750-4500 r/min
350 @ 1800-2800 r/min
320 @ 1750-4500 r/min
380 @ 1750-4500 r/min
320 @ 1750-4500 r/min
380 @ 1750-4500 r/min
Valve mechanism
4 valves per cylinder
4 valves per cylinder
4 valves per cylinder
4 valves per cylinder
4 valves per cylinder
4 valves per cylinder
4 valves per cylinder
Bore x stroke (mm)
85 x 88.1
82 x 93.8
85 x 88.1
82 x 93.8
82 x 93.8
82 x 93.8
82 x 93.8
Fuel system
2.0 Turbo Diesel
2.0 Petrol
2.0 Turbo Diesel
2.0 Petrol
2.0 Turbo Petrol
2.0 Petrol
2.0 Turbo Petrol
Emission controls
Euro IV
Euro IV
Euro IV
Euro IV
Euro IV
Euro IV
Euro IV
Compression ratio
16.5
10
16.5
10
10
10
10
Transmission
6MT
6AT
6MT
6AT
8AT
6AT
8AT
Powertrain management system
—
✓
✓
✓
✓
✓
✓
Rear differential lock
✓
✓
✓
✓
✓
✓
✓
Front suspension
Double wishbone/coil spring front independent suspension
Double wishbone/coil spring front independent suspension
Double wishbone/coil spring front independent suspension
Double wishbone/coil spring front independent suspension
Double wishbone/helical spring front independent suspension
Double wishbone/coil spring front independent suspension
Double wishbone/helical spring front independent suspension
Rear suspension
Five-link/coil spring non-independent suspension
Five-link/coil spring non-independent suspension
Five-link/coil spring non-independent suspension
Five-link/coil spring non-independent suspension
Five-link/helical spring non-independent suspension
Five-link/coil spring non-independent suspension
Five-link/helical spring non-independent suspension
Drivetrain
4WD
4WD
4WD
4WD
4WD
4WD
4WD
Emissions standard
Euro IV
Euro IV
Euro IV
Euro IV
Euro IV
Euro IV
Euro IV
Wheel
265/65 R17
265/65 R17
265/65 R17
265/65 R17
265/65 R17
265/65 R17
265/65 R17
17" alloy wheels
Single colour
Single colour
Dual tone
Dual tone
Dual tone
Dual tone
Dual tone
Wheel
Full size
Full size
Full size
Full size
Full size
Full size
Full size
Front grille
Silver
Silver
Silver
Silver
Silver
Silver
Silver
Side step
✓
✓
✓
✓
—
✓
✓
Removable hard top
✓
✓
✓
✓
✓
✓
✓
Red tow hooks - front & back
✓
✓
✓
✓
✓
✓
✓
Door outside handle
Black
Black
Black
Black
Black
Black
Black
Rear door ouside handle
Black
Black
Black
Black
Black
Black
Black
Halogen headlights
✓
✓
✓
✓
✓
✓
✓
Height adjustable headlights - electric
✓
✓
✓
✓
✓
✓
✓
Front & rear fog lights
✓
✓
✓
✓
✓
✓
✓
LED Daytime Running Lights
✓
✓
✓
✓
✓
✓
✓
Follow me home lights
✓
✓
✓
✓
✓
✓
✓
LED high mount brake light
✓
✓
✓
✓
✓
✓
✓
Outside rear view mirror - electric heat
Chrome
Chrome
Chrome
Chrome
Chrome
Chrome
Chrome
Cruise Control
—
✓
—
✓
✓
✓
✓
Dual zone auto air conditioner
✓
✓
✓
✓
✓
✓
✓
Power sterring
✓
✓
✓
✓
✓
✓
✓
Multi-function sterring wheel
✓
✓
✓
✓
✓
Leather
Leather
Electric windows, front and rear
✓
✓
✓
✓
✓
✓
✓
Anti-glare inside rear view mirror
✓
✓
✓
✓
✓
✓
✓
Driver's seat - 4-way adjustable
Manual
Manual
Manual
Manual
Manual
Electric
Electric
Front passenger seat- 6-way adjustable
✓
✓
✓
✓
✓
✓
✓
Rear seat configuration
60:40 fold, flip
60:40 fold, flip
60:40 fold, flip
60:40 fold, flip
60:40 fold, flip
60:40 fold, flip
60:40 fold, flip
Rear seat recline function
✓
✓
✓
✓
✓
✓
✓
Rear centre armrest & cupholder
✓
✓
✓
✓
✓
✓
✓
AM/FM radio?MPS
✓
✓
✓
✓
✓
✓
✓
6 speakers
✓
✓
✓
✓
✓
✓
✓
Bluetooth
✓
✓
✓
✓
✓
✓
✓
Auxillary & USB functionality
✓
✓
✓
✓
✓
✓
✓
Anti-lock Braking System (ABS)
✓
✓
✓
✓
✓
✓
✓
Electronic Brake force Distribution (EBD)
✓
✓
✓
✓
✓
✓
✓
Electronic Stability Programme (ESP)
—
—
✓
✓
✓
✓
✓
Emergency Brake Assist (EBA) - function steering wheel
—
—
✓
✓
✓
✓
✓
Traction Control System (TCS)
—
—
✓
✓
✓
✓
✓
Hill Ascent Control (HAC)
—
—
✓
✓
✓
✓
✓
Hill Descent Control (HDC)
—
—
✓
✓
✓
✓
✓
Electronic Parking Brake (EPB)
✓
✓
✓
✓
✓
✓
✓
ISO- FIX child seat restraint system
✓
✓
✓
✓
✓
✓
✓
Child safety lock
✓
✓
✓
✓
✓
✓
✓
Front 3-point safety belts with pre-tensioners
✓
✓
✓
✓
✓
✓
✓
Driver airbag
✓
✓
✓
✓
✓
✓
✓
Front passenger airbag
✓
✓
✓
✓
✓
✓
✓
Tyre Pressure Monitoring System (TPMS)
✓
✓
✓
✓
✓
✓
✓
Parking sensors rear
✓
✓
✓
✓
✓
✓
✓
Reverse camera system
✓
✓
✓
✓
✓
✓
✓
Alarm
✓
✓
✓
✓
✓
✓
✓
Immobiliser
✓
✓
✓
✓
✓
✓
✓
Central locking
✓
✓
✓
✓
✓
✓
✓
Length (mm)
4645
4645
4645
4645
4630
4645
4630
Width (mm)
1925
1925
1925
1925
1925
1925
1925
Height (mm)
1871
1871
1871
1871
1871
1871
1871
Wheelbase (mm)
2745
2745
2745
2745
2745
2745
2745
Fuel tank capacity (l)
75
75
75
75
75
75
75
Curb weight (kg)
2140
2110
2140
2110
2080
2110
2080
Gross Vehicle Mass/GVM (kg)
2565
2535
2565
2535
2505
2535
2505
Approach angle (degrees)
37
37
37
37
37
37
37
Departure angle (degrees)
31
31
31
31
31
31
31
Rampover angle (degrees)
23
23
23
23
23
23
23
Ground clearance (mm)
210
210
210
210
210
210
210
Luggage capacity (litres) *seats down
532/965*
532/965*
532/965*
532/965*
532/965*
532/965*
532/965*
5-year / 120,000 km Warranty
✓
✓
✓
✓
✓
✓
✓
4-year / 60,000 km Service Plan
Optional
Optional
Optional
Optional
Optional
Optional
Optional
Service intervals (km)
15,000
15,000
15,000
15,000
15,000
15,000
15,000
Model
Specs
Service Plan Package
Service Plan Package Price (Incl VAT)
B40 PLUS
B40 PLUS Diesel Models
4 years/ 60,000km
R 35,000
B40 PLUS
B40 PLUS Petroll Models
4 years/ 60,000km
R 25,000
